Installation Guide

Follow these steps carefully before and during installation of the MagGuard®.

Download Full Specification Sheet (PDF)

Installation Steps

  1. 1

    Before using the MagGuard, conduct a thorough inspection. Check for any damage to the cap; if you notice any deformities or damage, please dispose of the cap, as using a damaged one could lead to serious injury.

  2. 2

    Inspect the internal magnet collar for metal shavings, concrete dust, or debris. Debris coating the magnet can reduce retention force. Clean with a dry cloth before installing. After installing, confirm the cap holds securely in the vertical position without manual support before leaving the area.

  3. 3

    Verify that you are using the correct size MagGuard protective cap for your specific threaded rod size before installation.

    ImperialMetric
    1/4" – 5/16"6mm – 8mm
    3/8" – 1/2"10mm – 12mm
    5/8" – 3/4"16mm – 19mm
    7/8"22mm
  4. 4

    Verify the threaded rod meets the minimum required threaded rod length of 1.25".

  5. 5

    Attach optional hazard warning flag at the designated attachment point.

  6. 6

    Firmly place the MagGuard onto the end of the exposed threaded rod and apply pressure until the internal magnet makes contact with the rod end.

  7. 7

    To ensure a secure attachment, the MagGuard must be vertically centered on the end of the protruding threaded rod.

Quick Reference

Specifications

VisibilityHigh visibility colors: red, orange, yellow, green, and blue
MaterialHomopolymer Polypropylene (PP)
MagnetNeodymium rare earth magnet
Compatible Sizes1/4" to 7/8"
Intended UseAt-grade or above-grade applications only. Not intended for below-grade impalement protection.

Magnet Safety Warnings

!

Strong Magnet

Handle with care. May cause injury or damage.

!

Medical Devices

Keep away from pacemakers and other implantable devices.

!

Electronics

Keep away from phones, credit cards, hard drives, watches, and sensitive electronics.

!

Temperature & Environment

Do not expose to extreme heat or corrosive conditions. May lose magnetic strength.

!

Magnetic Strength

Holding power varies with surface material, coatings, rust, or debris. Confirm adherence before use. Do not rely solely for safety-critical tasks.

Keep out of reach of children. Not a toy. Product does not support additional suspended loads.

MagGuard® properly installed on an active job site

Have questions about installation?

Our team is available to assist with any questions before or during deployment.

Contact UsView FAQ

Terms of Use

MagGuard® is intended for use in accordance with all applicable federal, state, and local safety regulations, including OSHA standards. Users are solely responsible for determining the suitability of this product for their specific application and ensuring compliance with all applicable requirements.

ProStrux® LLC assumes no liability for injuries, damages, or losses resulting from improper installation, misuse, unauthorized modification, or use outside the intended application. This product is not a substitute for a comprehensive jobsite safety program.

By using this product, the user acknowledges they have read and understood these instructions and accepts full responsibility for proper installation and use.
